Ultimate Tumbler Screener

The movement of a tumbler screener is often compared with simple hand screening similar to the “gold washing pan”. The heart of the Ultimate Tumbler Screener is the patented 3D adjustment system used in setting the individual retention time of any product that needs to be screened. The main shaft is driven by V-belts and an electric motor. Using a special axially spring-mounted graphic recorder, this 3D movement of the machine can be drawn on paper two dimensionally in the form of an ellipse and then measured exactly. The measured data can be transmitted at any time for further checking. In this way, optimum settings will always be available and reproducible in the future, too.

Add To Compare

Downloads

Here you can download Brochures and datasheets to further inform you about this machine’s technology and specifications.

BENEFITS

Most important advantages

Extremely high screening efficiency obtainable by means of individually adjustable retention time for any product and capacity
Delivered operationally ready and adjusted to each product
Up to 7 fractions simultaneously on each machine
Low acceleration, long service life of all parts, no product destruction
Up to 100% availability in 24h operation with few maintenance requirements
Tough modular design, no dead corners, low part weights
Heavy pyramid base to counterbalance the rotating body
100% statically and dynamically balanced for vibration free installation in steel structures
Automatic centering of screening inserts and strong intermediate rings and covers for simple and fast assembly and screen changing
Low construction height by means of reduced intermediate ring heights of 80 mm for best screen results on all decks
100% dustproof thanks to simple fast-mounting Silicone clip-on gaskets on the intermediate rings, thereby dispensing with the requirement to exchange the formerly used U-shaped gaskets on the screen inserts
Easy dismantling and cleaning of all parts down to the conical base
Low noise level of approx. 75 db(A)
Optional: quick clamps for maximum time saving when changing screens
Favorable prices and short delivery times

SPECIFICATION

MACHINE NAME

Ultimate Tumbler Screener

APPLICATION

Agriculture, Chemical Powders, Cosmetics, feed, food, Metal powder, Minerals, Pharmaceuticals

MOTION

SCREEN SURFACE AREA

NUMBER OF SEPARATIONS

Up to 2, Up to 3, Up to 4, More

MESH OPENINGS

20 μm – 20 mm

FEED RATES

1 kg/h – 50.000 kg/h

ANTI BLINDING SYSTEM

Rubber balls, Ultrasonic, rotating air nozzles, rotating roller brushes; combinations availably upon request

DIMENSIONS

Smallest – 660mm (Diameter) Largest – 2650mm (Diameter) Heights dependant upon number of decks.

MACHINE MATERIAL

Carbon steel, stainless and special steels, rubber materials FDA compliant

SCREEN MATERIAL

WEIGHT

280kg (smallest) – 2900kg (largest)
