Eriez Vibratory Screeners

Eriez’ Vibratory Screeners provide solutions to industry’s demand for dependable material separation at an affordable price. The wide range of models available allows selection of units for specific and unique material application requirements. These ideal machines are available for processing slurries, waste water, minerals, chemicals and other dry or dewatering applications.

Add To Compare

Downloads

Here you can download Brochures and datasheets to further inform you about this machine’s technology and specifications.

Download Brochure9 MB

BENEFITS

Features & Benefits:

Rugged construction
Long life
Simple controls
Easy installation
Low power consumption
Special Tray Size
Bias Discharge
Enclosed Trays
Tool-less Screen and Cover Removal
Base or Suspension Mounting
Tube Trays
Inspection Parts/ Windows
Sanitary Construction
Hazardous Environment Class II. Div. I. Grp F, G Acceptable

SPECIFICATION

MACHINE NAME

Eriez Vibratory Screeners

APPLICATION

Chemical Powders, feed, food, Metal powder, Minerals, Paper & pulp, Plastics

MOTION

Linear horizontal

SCREEN SURFACE AREA

10, 25, 50

NUMBER OF SEPARATIONS

Up to 2, Up to 3

MESH OPENINGS

Information not available

FEED RATES

Information not available

ANTI BLINDING SYSTEM

Information not available

DIMENSIONS

Various options available 24 inches (w) x 60 inches (l) Smallest 48 inches (w) x 120 inches (l) Largest

MACHINE MATERIAL

Steel

SCREEN MATERIAL

Information not available

WEIGHT

Information not available
